Vermont Indexable Tooling has an indexable carbide insert centering drill to
produce your 90 deg include angle spots. This simple and strong
centering drill works great on a multitude of materials and can be used for much more than
just spotting your drills.
Tool Specifications:
V8000 - 3/8"
IC insert |
|
V8120 - 1/4"
IC insert |
Included angle - 90º
Shank - Ø.750
Overall length - 3.7”
Max Spot Diameter - Ø.86
Coolant Style |
|
Included angle - 90º
Shank - Ø.375
Overall length - 2.25”
Max Spot Diameter - Ø.52
Coolant Style |
| Suggested Starting Points |
|
|
| Low
Carbon and Mild Steels under 180 BHN |
SFM 400-1200 |
IPR – .001 |
| High
Carbon and Alloy Steels under 30Rc and 400 Series Stainless |
SFM 250-700 |
IPR – .001 |
| High
Carbon and Alloy Steels between 30 and 40Rc |
SFM 200-500 |
IPR – .001 |
| 300
Series; Stainless Steels pH Stainless Steels |
SFM 250-600 |
IPR – .001 |
Types of machines that it can be used on:
(but not limited to):
Lathe – Manual or CNC
Mill – Manual or CNC
New Machines
Old Machines
And Many More
They are
not just for centering:

Centering
Facing

Grooving
OD Chamfer
Plunge, Edge Break and more
The new 90° indexable carbide centering drills are just
some of the many new tool styles that we will soon be adding to our already popular line
of stock tools.
VIT designs and
manufactures a wide variety of custom indexable carbide insert tooling!
